Overview
The A-25 2.5 t Electric Forklift is engineered for demanding material handling environments. Building on the reliable A-20 platform, it delivers a 50% increase in motor power and a reinforced 148-type steel mast, enabling it to handle loads up to 2,500 kg with superior strength and agility.
Designed for productivity and operator comfort, this model combines enhanced performance with a compact footprint, making it ideal for high-intensity applications in warehouses, manufacturing plants, and industrial yards.
Product Parameters
|
Rated Load Capacity |
2500kg |
Maximum Lifting Speed (Unloaded) |
200mm/s |
|
|
Overall Length |
Without Forks |
2450mm |
Maximum Lifting Speed (Loaded) |
160mm/s |
|
With Forks |
3670mm |
Minimum Turning Radius |
2550mm |
|
|
Overall Width |
Wheel Width |
1200mm |
Maximum Travel Speed (Unloaded) |
10.5km/h |
|
Frame Width |
1080mm |
Maximum Travel Speed (Loaded) |
10km/h |
|
|
Overall Height |
Height with Mast Lowered |
2150mm |
Maximum Gradeability (Loaded) |
15% |
|
Overhead Guard Height |
1980mm |
Load Center Distance |
500mm |
|
|
Maximum Operating Height |
3880mm |
Front Wheel Specification |
23×9-10 |
|
|
Wheelbase |
1710mm |
Rear Wheel Specification |
18×7-8 |
|
|
Front Overhang |
480mm |
Lifting Motor Power |
7.5 kW AC |
|
|
Front Wheel Track |
960mm |
Drive Motor Power |
7.5 kW AC |
|
|
Rear Wheel Track |
960mm |
Steering Type |
Hydraulic Power Steering |
|
|
Minimum Ground Clearance |
Mast Lower End (Empty/Loaded) |
105mm |
Charging Input Voltage |
220V |
|
Frame Center Height (Empty/Loaded) |
150mm |
Charging Time |
3-5h |
|
|
Maximum Lifting Height (Unloaded) |
3000mm |
Battery Type |
Lead-acid Battery |
|
|
Free Lift Height |
45mm |
Battery Capacity |
140Ah |
|
|
Mast Tilt Angle (Forward/Rearward) |
5/10° |
Rated Voltage |
60V |
|
|
Machine Weight (Standard, Unloaded) |
3300kg |
Operating Time (per charge) |
4-5h |
|
|
148-type Special Steel Mast. Lithium-ion Battery Optional. |
||||
Advantages
Power & Performance
- 7.5 kW AC Motors (Drive & Lift): Delivers 50% more power for faster acceleration, higher lift speeds, and reliable performance on inclines.
- 148-Type Reinforced Steel Mast: Ensures structural integrity and durability during frequent heavy-load operations.
- Large 23x9-10 Front Tires: Provides improved stability, traction, and load distribution.
Efficiency & Uptime
- Long Battery Life: 60V / 140Ah lead-acid battery supports 4–5 hours of continuous use (lithium option available).
- Fast Recharge: Full charge in 3–5 hours, minimizing downtime.
- Compact & Agile: Maintains a tight 2,550 mm turning radius for easy maneuvering in confined spaces.
Durability & Safety
- Robust Chassis (3,300 kg): Enhances stability and safety during heavy lifting and transport.
- Operator-Focused Design: Features hydraulic power steering, ergonomic controls, and clear visibility for reduced operator fatigue.
Applications
The A-25 2.5 t Electric Forklift is designed for industries that require reliable and efficient heavy-load handling:
- Steel & Metal Fabrication
- Construction & Building Materials
- Heavy Machinery & Equipment Handling
- Logistics & High-Throughput Warehousing
- Port & Rail Operations
- Manufacturing & Assembly Plants
